KTM Macina Fogo 273 Electric Bike 2017


KTM Macina Fogo 273 model 2017, the new MTB line for all occasions

KTM Macina Fogo 273, an absolute innovation in 2017 by the Austrian company, is a single suspension ebike with aluminum frame with optimum performance for all uses, both leisure and off-road. Thanks to high level components and the use of the latest technologies is in the construction of the frame and in that the propulsion system. With the use of complete gear and the hydraulic brake Shimano, this MTB allows the user to experience immediate comfort. Thanks to the couple of new Bosch Performance CX motor and the 500Wh battery. The fork is chosen Suntour Aion 35 that amortize in an efficient way on more uneven grounds. KTM Macina Fogo 273 is suitable for both cycling and routes that are more challenging than the usual paths open to a broad audience. Black color and KTM white details and wheels 27.5" Plus!

Components of MTB KTM Macina Fogo 273

The electric MTB KTM Macina Fogo 273 has a single suspension system of hydroformed aluminum frame built with new technology gravity casting, wheels 27.5" Plus with tire Schwalbe Nobby Nic Tubeless Ready Snakeskin Apex (measuring 70-584) mounted on a rim KTM Line Tubeless, the fork Suntour Aion 35 with 110mm of excursion and lockable handlebar. The gear is Shimano to 11 speeds with lever SLX M7000 to 11 speeds, derailleur Deore XT M8000 Shadow Plus and sprocket Deore XT M8000 of 11 pinions with 11 to 46 teeths, which allows fast and accurate change in any situation. The hydraulic braking system is the Shimano SLX M7000 with 180mm discs and pads with forced cooling. Ultimately the eBike Macina Fogo 273 has all the features of the top range with outstanding qualities as off-roaders on any terrain and slope.

The propulsion system MTB KTM Macina Fogo 273 2017

The model Macina Fogo 273 mounts the latest evolution Bosch motor, the Performance CX. The electronic motor Performance CX processes data from different sensors, torque, speed, cadence that collects pulses a thousand times per second, thereby ensuring efficiency at the highest level. Because of this combination the motor results in very fluid in the delivery 75nm of torque up to speed of 25 Km/h which is limited by the law. The dashboard Intuvia, mounted as standard with handlebar comand, allows you to view all the most important information for the user, to charge any type of external device with a USB port, to advise the best time to change and manage the degree of assistance naturally. The power supply is entrusted to the lithium-ion Bosch from 500Wh to 13.9Ah that is recharged in just 3.5 hours, thanks to the charger that came with the ebike.


  • Propulsion system: Bosch Performance CX 250W, display Intuvia
  • Battery: Bosch Powerpack Lithium 500Wh, 13.9Ah
  • Frame: Macina Fogo 27.5" aluminum, boost, total weight 22.0Kg
  • Fork: Suntour Aion 35L, 110mm of excursion
  • Brakes: Shimano SLX M7000, discs 180/180
  • Gear lever: Shimano SLX M7000, 11 gears
  • Derailleur: Shimano Deore XT M8000 shadow plus
  • Sprocket: Shimano Deore XT M8000, 11 pinions 11 to 46 teeth
  • Circles: KTM Line Tubeless - DT Swiss Boost
  • Tires: Schwalbe Nobby Nic da 27.5" Plus, measuring 70-584 Tubeless Easy, Snakeskin, Apex
